Features
1). Adopt wheel labeling way;
2). Label transmit via label wheel, run along the guide rail and operate the labeling work;
3). When the label through the appointed wheel, the sensor will automatically detect I-Mark;
4).Once confirms the electronic eye position, the demodulator will automatically adjustment the speed of wheel, and then appoints the label cutting position accurately.
5).The label through the wheels and then enter into the cutting part to carry out the label cutting work, the label cut will be send to the vacuum-grip cylinder.
6). The containers which is transmitted by conveyor belt will be arranged properly via star wheel, then, the label which has been painted with glue will proceed the first labeling in the roller area, last, rely on the synchronous belt to proceed the last labeling operation.
1).The adjustment of label cutting blade is easy and simple.
2).Vacuum-grip cylinder is made of high hardness material, the additional old handler can reduce the frictions of labels and
prevent static electricity.
3).The change-over of shape pars can be finished within 10 minutes;
Device parameters
No. |
Item |
SPC-150B |
SPC-250B |
1 |
Import Power |
3.0KW |
3.0KW |
2 |
Import Voltage |
∮3, 380/220VAC |
∮3, 380/220VAC |
3 |
Capacity(production speed) |
150 bottles per min |
2×150bottles/min |
4 |
Dimension of Host Machine (mm) |
L2100×W850×H2000 |
L3200×W1200×H2070 |
5 |
Applicable Diameter Container (mm) |
φ28mm ~ φ120mm |
φ28mm ~ φ120mm |
6 |
Applicable Label Length (mm) |
30mm~250mm |
30mm~250mm |
7 |
Applicable Thickness Label (mm) |
30mm~250mm |
30mm~250mm |
8 |
Applicable Inner Diameter of Paper Tube |
5"~10" |
5"~10" |
